Haulmark 6x12 Transports
CARDINAL SALES
2501 Broad St (SR. 38),
NEW CASTLE , INDIANA  47362
765-529-2677
FACTORY PICKUPS
Option. Chrome Center Cap $15.
and Wheel Ring $15.
Chrome Corners Option
Option Keyed RV Latch, With Keys
Getting your money's worth?
The new Transport delivers more features than any competing brand. Features like one piece aluminum roof, .080 aluminum top edge wrap, an exclusive TPO front cap, two rear ramp door support cables, 3/4-inch plywood floor, wall studs on 16-inch centers, tube frame design instead of more common I-beam and the only "automotive model" warranty in the industry. This smart value tag hitch trailer is ideal for light- to medium-duty hauling. Yet, it has the look and features of other Haulmark trailers. For a more aerodynamic look, select the NEW OPTIONAL V-NOSE, available on all 5 ft. through 8-1/2 ft. models.

Features
            Benefits

One piece aluminum roof     .....
                                                      ..    No more seams in the roof

.080 aluminum top edge wrap ...
                                        ... Resists denting and provides additional strength

Exclusive TPO front cap ..
                              .. Doesn't fade like fiberglass and doesn't crack like ABS

Two rear ramp door support cables ..
                                            ... Facilitates smoother and more stable operation

3/4 inch plywood floor  ..
                             .......More strength and durability to support your load

Wall studs on 16 inch centers  ...
                                  .. Reduces sidewall flex and adds strength to walls

Tube frame design instead of more common I-beam ...
                                              Increased structural rigidity that provides solid foundation



Haulmark Factory Specs. From There Web Site. www.haulmark.com
Exterior
Length: 12ft Long
Width: 6ft Wide

Interior

Loading and Towing
2,000lb Tongue Jacks: 2,000lb Silver Powder Coated Top Wind Tongue Jack
Hitch Type: Tag
Jack Accessories: Sand Pad
Safety Chains: 5,000lb Silver Safety Chains w/S Hook
GVWR: 2990

Suspension
Tires: ST205/75D14 C Rated Tires
Wheels: 14in 5 Hole White Spoke Wheels
Axle Width: Standard Track
Hub Type: EZ-Lube Hubs
Suspension: Spring Suspension
Weight: 3,500lb Axles

Brakes
Brake Type: No Brakes

Doors
Rear Doors: Cam-Lock Double Rear Door
Side Doors: 32in Bar-Lock Side Door
Construction
Cap: Polar White Cap
Crossmember Spacing: Crossmembers 24in On Center
Crossmembers: Z Crossmembers
Finish: .030 Aluminum Exterior
Floor Covering: 3/4in Plywood Floor Covering
Main Rails: 2in x 3in Tube Main Rails
Roof: 1-Piece Aluminum Roof
Roof Bow Spacing: Roof Bows 24in On Center
Roof Bows: Hat Section Roof Bows
Sidewall Liner: 3.6mm Lauan Sidewall Liner
Top Wrap: .080 Aluminum Top Wrap
Vertical Post Spacing: Vertical Posts 16in On Center
Vertical Posts: 60-3/4in Z Posts

Additional Specs
A-Frame Couplers: 2in 5,000lb Coupler
Bolt Pattern: 5 Bolt Pattern
Frame Type: Steel Frame





6x12SA Haulmark Transports
with 6" package side door, stone guard, jacks, 1 light, 1 switch, rear Ramp door
Bristol Indiana & Fitzgerald, Georgia $2599. Factory Pickup Prices
McAdoo, PA $2599.  Duncan, OK $2599.Springville, Utah $2599. El Mirage, AZ $2599.
Plus Haulmark pickup fee. Indiana & Georgia $50. UT, AZ,OK, PA $100. If Shipped no fee.
Roof Vent $49. extra Double rear doors no ramp door -$150.
   CORRECT 9-4-2009
Haulmark 6X12 Transport  with Package. 16" on center walls
